MICRO OWL 2 OPTICAL POWER METER
The Micro OWL 2 is one of the world’s smallest optical power meters to offer so many features, including a 0.15 dB accuracy over its normal operating range. It is as feature-packed and accurate as optical power meters costing hundreds of dollars more. This combination of features, size, accuracy, and price make it a tremendous value for the optical fiber professional.

The Micro OWL 2 is a high accuracy, high resolution, microprocessor controlled, optical power meter. It has an small handheld case made from high impact plastic, a backlit, graphic, liquid crystal display, and 18-key keypad for easy data entry. It can be ordered with an integrated visual fault locator (in the place of the battery charger). The meter will operate for over 100 hours on a standard 9v battery and has built-in automatic shutdown.

The Micro OWL 2 includes a built-in Link Wizard that calculates the allowable loss for the fiber runs that you will be measuring. The meter stores physical fiber characteristics for eight different locations, or links. This includes: link name, date, fiber type, fiber length, connectors, splices, temperature, and calculated or entered reference power values for three wavelengths.

In addition the meter will store up to 1000 measured data points with labels. Each value includes the fiber type and link. The stored information can be selectively viewed, edited (measured again), printed, or deleted. The meter will print formatted reports of selected stored data directly using the built in USB port, or all of the stored data can be downloaded to our free OWL Reporter™ data management and reporting software.


Micro OWL 2 Optical Power Meter Sales Video


CLICK HERE FOR KIT VERSION

HELPFUL VIDEOS


VIDEO:

Micro OWL 2 Sales Video


VIDEO:

Choosing a Test Kit


VIDEO:

Universal Ports


VIDEO:

Mandrels


VIDEO:

Replacing the Battery


VIDEO:

Cleaning Optical Ports


VIDEO:

Interpreting OWL Reporter Certification Reports


VIDEO:

Removing Link Information and Stored Data


VIDEO:

Merging OWL Reporter Data Files


VIDEO:

storing Data in Micro OWL Certification Power Meters




(click image for larger, more detailed picture)
KEY BENEFITS
  • InGaAs photodetector
  • 2.5mm / 1.25mm universal connector
  • Multimode and singlemode ready
  • NIST Traceable
  • Separate zero reference for each calibrated wavelength
  • Small, hand-held size
  • Ergonomic protective rubber boot
  • Built-in Loss Wizard certifies fiber links against a myriad of national and international cabling standards
  • Up to 1000 stored data points
  • USB Data Interface
  • Free OWL Reporter PC software for printing professional certification reports
  • Long battery life: over 100 hrs. on a 9v alkaline battery
  • Large backlit LCD display
  • Battery life, stored data, temperature and power units indicator
  • Versatile 18-keypad operation
  • Measurement range: +5 to -70 dBm
  • Absolute accuracy: +/- 0.15 dB
  • Resolution: 0.01dB
OPTIONAL



Flashing red Visual Fault Locator (VFL; also known as VFF)

Click the image to learn more about the integrated VFL port

PRICING
Part # Description Detector Type Dynamic Range Integrated VFL Price
MO-2 Micro OWL 2 InGaAs +5 to -70 dBm No 645.00
MO-2V Micro OWL 2 VFL InGaAs +5 to -70 dBm Yes 845.00

DOCUMENTS
Product Overviews Operations Guide Firmware Upgrade
Micro OWL 2 Micro OWL 2 series Operations Guide Micro OWL firmware upgrade page
Micro OWL 2 VFL

Miscellaneous
OWL Reporter Software (with USB driver support for Windows XP, Windows Vista, Windows 7, and Windows 8)
(Windows 2000 is not supported)
Quick Reference Guide Selector
Self-diagnostic Procedure Selector
Detector Port Cleaning Brochure
