1300 OWL LED Source
NOTE: THIS PRODUCT IS OBSOLETE AND HAS BEEN REPLACED BY THE Dual OWL 1300 Multimode Light Source (SKU: DO2-13xx)

The 1300 OWL is a cost effective, compact, handheld light source.  The temperature compensated outputs are calibrated to couple -20dBm  of optical power into multimode fiber.  The light source is offered with a single 1300nm source installed, and can be easily upgraded to include a 850nm source.

The source is simple to operate with a single switch controlling power and selecting the output wavelength.  LED indicators highlight the selected source and verify that battery power is sufficient to maintain the calibrated output power.

Key Benefits

bulletHighly stabilized
bulletTemperature Compensated
bullet-20dBm Calibrated Output (Customizable)
bulletCompact Size
bulletRugged & Economical
bulletExtended Battery Life
bulletLow Battery Indicator
bulletNIST Traceable
bulletAvailable with ST or SC connectors

Pricing
SKU # Description- (Click the links below to view the PDF data sheet) Price
DO-1300ST 1300nm Multi-mode Stabilized LED Light Source ST Connector 325.00
DO-1300SC 1300nm Multi-mode Stabilized LED Light Source SC Connector 340.00
DOU-850 Upgrade to 850  95.00

NEVER BUY ANY SOURCE WITHOUT U.S. GOVERNMENT N.I.S.T. TRACEABLE ACCOUNTABILITY !

Documents (Click the links below to view the PDF data sheet
Dual OWL Datasheet Dual OWL Manual

Products ship with owner's manuals on CD.  Adobe Acrobat Reader (tm) is required to view these documents.



OWL manufactures a complete line of fiber optic test equipment for a wide range of applications, including telco, WAN, MAN, LAN, CATV, IT, manufacturing, and laboratory.

OWL's complete line of fiber optic testers have capabilities ranging from simple optical power and optical loss measurement to complete standards-based fiber optic link certification for both multimode and singlemode fibers, including 10-Gigabit Ethernet!

Product lines include: optical power meters, light sources, talk sets, optical length testers, visual fault locators and serial plastic fiber transceivers. All OWL optical power meters and light sources are NIST traceable.

COMING SOON: optical time domain reflectometer (OTDR)

For more information or for assistance in choosing the right fiber optic test equipment for your needs, send us an information request and we would be happy to assist you.
